| Base weight | 257.21 kg |
|---|
| Leveling configuration | |
|---|
| Bucket used | |
|---|
| Bucket weight | 93.8 kg
207 lb |
|---|
| Lift capacity at full height | Measured at pivot
617 kg
1360 lb
Measured at 500 mm ahead of pivot
453 kg
999 lb
|
|---|
| Lift capacity at 59 in. (1500 mm) | Measured at pivot
771 kg
1700 lb
Measured at 500 mm ahead of pivot
595 kg
1312 lb
|
|---|
| Boom breakout force | Measured at pivot
1295 kg
2855 lb
Measured at 500 mm ahead of pivot
922 kg
2032 lb
|
|---|
| Bucket rollback force capacity | At maximum height
1205 kg
2657 lb
At 59-in. (1500-mm) lift height
1518 kg
3347 lb
At ground-level line
1188 kg
2619 lb
|
|---|
| Dimensions | Maximum lift height
2284 mm
90 in.
At full height - bucket level
2123 mm
83.5 in.
At full height - bucket dumped
1743 mm
69 in.
|
|---|
| Overall length | 3.122 m
10.24 ft |
|---|
| Overall height in carry position | |
|---|
| Digging depth | 76 mm
2.9 in. |
|---|
| Reach | At maximum height
773 mm
30.4 in.
At ground level - bucket level
1381 mm
54.4 in.
|
|---|
| Bucket angle | Dump angle, degrees
43 degree (angle)
Rollback angle, degrees
25 degree (angle)
|
|---|
| Cycle times | Loader raise, seconds
2.76 seconds
Loader lower, seconds
1.69 seconds
Bucket dump, seconds
2.91 seconds
Bucket rollback, seconds
1.72 seconds
|
|---|
