| Base weight | 281.09 kg |
|---|
| Leveling configuration | |
|---|
| Bucket used | Materials |
|---|
| Bucket weight | 93.8 kg
207 lb |
|---|
| Lift capacity at full height | Measured at pivot (U)
633 kgf
1393 lbf
Measured at 500 mm ahead of pivot (V)
457 kgf
1005 lbf
|
|---|
| Lift capacity at 59 in. (1500 mm) | Measured at pivot (W)
959 kgf
2109 lbf
Measured at 500 mm ahead of pivot (X)
745 kgf
1639 lbf
|
|---|
| Boom breakout force | Measured at pivot (Y)
1710 kgf
3769 lbf
Measured at 500 mm ahead of pivot (Z)
1209 kgf
2665 lbf
|
|---|
| Bucket rollback force capacity | At maximum height (VV)
822 kgf
1819 lbf
At 59-in. (1500-mm) lift height (XX)
1397 kgf
3079 lbf
At ground-level line (ZZ)
1335.4 kgf
2944 lbf
|
|---|
| Dimensions | Maximum lift height (A)
2616 mm
103.3 in.
At full height - bucket level(B)
2411 mm
94.9 in.
At full height - bucket dumped (C)
2003 mm
78.8 in.
|
|---|
| Overall length (I+F), ft (m) | 3.218 m
10.55 ft |
|---|
| Overall height in carry position (J) | |
|---|
| Digging depth (H) | 121 mm
4.76 in. |
|---|
| Reach | At maximum height (D)
766 mm
30.1 in.
At ground level - bucket level (F)
1491 mm
50.7 in.
|
|---|
| Bucket angle | Dump angle, degrees (E)
49.3 degree (angle)
Rollback angle, degrees (G)
23.8 degree (angle)
Dump angle, ground
138 degree (angle)
|
|---|
| Cycle times | Loader raise, seconds
3.6 seconds
Loader lower, seconds
2.1 seconds
Bucket dump, seconds
3.0 / 1.2 (with regen) seconds
Bucket rollback, seconds
1.8 seconds
|
|---|
